SORALUCE PM portal moving table milling machine

High precision and enhanced productivity for large size components

  • Advanced SORALUCE technology geared towards maximising productivity, precision and customisation: DAS system, Modular Quill, Vertical Ram Balance, Accura Heads, SSV and Adaptive Control.
  • SORALUCE head technology: a highly reliable, extensive range of SORALUCE quills and heads
  • Automatic head and tool changing systems
  • SORALUCE Digital, Data System: a comprehensive monitoring package with continuous information of machine and process status
  • Precise and efficient machining results
  • Excellent dynamics thanks to the rapid travel of the axes
  • High power and torque for high performance machining
  • Improved stability to enable high stock removal for prismatic components in a single set-up belonging to the mechanical engineering, energy and capital goods industries
  • One or two operator’s platforms with their respective control panels, thus allowing the best location of the operator in each operation
  • Total machine concept design: a complete working area analysed for optimal comfort, safety and ergonomics (maintenance spots, operator area)





PM

Table length

mm

5000 / 6000 / 7000

Table width

mm

2500 / 3000

Longitudinal traverse "X" axis

mm

5600 / 6600 / 7600

Cross traverse "Y" axis

mm

4500 / 5000

Vertical traverse, Ram "Z axis"

mm

1500 / 2000

*Vertical traverse, Cross beam "W"

mm

1000 / 1500 / 2000

Clearance between columns

mm

2500 / 4000

Clearance height

mm

2100 / 2600 / Up to 4100 (Machine with "W" axis)

Spindle power

kW

43 / 60

Spindle speed range

min-1

4000 / 5000 / 6000 / 7000

Spindle nose taper



ISO-50 / HSK-100

Rapid traverse

mm/min-1

X = 30000, Y/Z = 35000

CNC system



Heidenhain TNC 640 / Siemens 840 D SL

Coolant system



External coolant system via spray rose ring / Internal coolant system up to 70 bar

Tool magazine

No. tools

40 / 60 / 80 / 100 / 120

*Optional

Customisation

Select your head:

Technical data

It enables for:

  • Automatic indexing of vertical and diagonal articulations.
  • Automatic tool changing.
  • Automatic head changing.
  • Internal / external cooling system.
  • Suitable for any type of taper and pull-studs.
  • Different clamping forces for different tools.
  • Suitable for setting different accessories.
  • 22 / 24 / 28 / 37 / 43 / 46 / 55 kW
  • 2.5° x 2.5° / 0.001° x 0.001°
  • 4000 / 5000 / 6000 / 7000 min-1

Technical data

It enables for:

  • Automatic indexing of vertical and horizontal articulations.
  • Automatic tool changing.
  • Automatic head changing.
  • Internal / external cooling system.
  • Suitable for any type of taper and pull-studs.
  • Different clamping forces for different tools.
  • Suitable for setting different accessories.
  • 37 / 43 / 46 kW
  • 1º x 1º
  • 4000 / 5000 min-1

Technical data

  • 5-axis continuous indexing head, indexing at 0,001ºx0,001º
  • Full 5 axis machining or use for fast positioning
  • Automatic tool changing.
  • Automatic head changing
  • Cooling through the spindle
  • Different clamping forces for different tools.
  • Suitable for setting different accessories.
  • Spindle locking option (turning operations)
  • Available for SORALUCE FP, FR and FXR models
  • 37 kW
  • 0.001° x 0.001°
  • 7000 min-1

Technical data

It enables for:

  • Automatic tool changing.
  • Automatic head changing.
  • Internal / external cooling system (no external tubes exposed to chips).
  • Suitable for any type of taper and pull-studs.
  • Different clamping forces for different tools.
  • Suitable for setting different accessories.
  • Flexibility
  • Interchangeability
  • Options
  • C Axis
  • Maintainability
  • 43 / 46 / 49 / 81 / 106 kW
  • 2000 / 3000 / 4000 / 5000 min-1

Technical data

  • Special angular heads (railway bogie, motor block, etc.).
  • Special adaptors

Technical data

  • NC Facing heads
  • Angular heads
  • 5 axis heads
  • Electrospindles

Technical data

  • Heavy duty angular head
  • Angular and horizontal extensions
  • Turning adaptors
  • O&G oriented heads
  • Rotary couplings

Working Stations

Angle plates

Angle plates

Applications

Machining Test

Try the machining test service on our machines with your workpieces. Put the capacity of our machines and our process team to the test, to be absolutely sure about your investment.

Challenge us
